    Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : jnhtc
    Certification : CE, ISO9001, CCC
    Price : USD32000-48000
    Payment Terms : L/C, T/T
    Supply Ability : 1000 units per month
    Delivery Time : 20days
    • Product Details
    • Company Profile

    Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane

    Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane

    3 Axles 12 weheels container 50 tons heavy duty Van Semi Trailer 0

    Detailed Photos

    Chassis
    Chassis Type
    SINOTRUK HOWO 6X4 DUMP TRUCK WITH CRANE
    Chassis model
    ZZ1317V3267B1
    Wheelbase (mm)
    3200mm
    Engine
    Model
    WP12.400E201, Euro II (optional)
    Type
    Diesel
    Horsepower
    371HP
    Option
    From 336HP to 420HP for option
    Gear box
    HW19710,10 forward & 2 reverse
    Cab
    Type
    HW76 cab(optional)
    Braking system
    Drive brake
    Hydraulic drum
    Parking brake
    Cutting-off air brake
    Tire
    12.00R20 radial tire with one spare
    Front axle
    VG95 (drum)
    Rear axle
    MCP16ZG(twin axle, drum, Ratio 5.26)
    Fuel tank (L)
    400L
    Cargo box
    Carriage dimension
    7500*2300*600mm(optional)
    Thickness
    Bottom 3mm, side 1.5mm(optional)
    Crane
    Capacity
    12 tons(optional)
    Type
    Straight arm/Knuckle
    Lifting height
    12.5m(optional)
    Delivery time
    About 30 days after prepayment

    Crane truck

    Crane truck, also known as truck mounted lifting and transportation vehicle, is a device that uses hydraulic lifting and telescopic systems to lift, rotate, and lift goods. It is usually installed on cargo trucks. It generally consists of a truck chassis, cargo compartment, power take-off, and crane. According to the type of crane, it is divided into straight arm type and folding arm type. According to tonnage, it is divided into 2 tons, 3.2 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, and 20 tons.
    Precautions during the operation of the on-board crane:
    1) Understand the size of the lifted cargo, find the distance from the center of the cargo to the center of the crane column, and check the lifting capacity parameters of the crane based on the distance. 2) The lifting capacity (torque) of the crane is fixed, and the larger the working radius of the crane. The lighter the lifted cargo, the smaller the working radius, and the heavier the lifted cargo. (The working radius refers to the horizontal distance from the center of the torque to the hook.)- 3) Considering the lifting capacity of the crane and the load-bearing capacity of the chassis, the larger the beam, the better. If the crane is larger and the chassis is smaller, it will cause deformation and fracture of the beam. A smaller chassis reduces the power of the engine, which affects the lifting capacity of the crane. So when considering a 230mm beam, we choose a crane weighing less than 3 tons. When considering a 250mm beam, consider a crane weighing less than 6 tons. A 280mm beam can be equipped with a crane weighing less than 8 tons. A crane weighing less than 10 tons can be considered for chassis with rear eight wheels and front four wheels.

    In the engineering construction, truck crane plays an important role. It assists workers to complete tasks such as lifting, loading and unloading, greatly improving work efficiency and reducing labor consumption. At the same time, the safety performance of the crane is also concerned, and the advanced safety device ensures the stability and safety of the lifting process.
    Truck crane, with its unique advantages and excellent performance, has become an indispensable tool in engineering construction. It has witnessed the successful implementation of numerous engineering projects, contributing to the development and construction of the city.


    Packaging & Shipping

    3 Axles 12 weheels container 50 tons heavy duty Van Semi Trailer 6

    3 Axles 12 weheels container 50 tons heavy duty Van Semi Trailer 7

    3 Axles 12 weheels container 50 tons heavy duty Van Semi Trailer 8


    Company Profile

    3 Axles 12 weheels container 50 tons heavy duty Van Semi Trailer 9


    FAQ

    Q. What is your payment terms ?
    A: 30% TT before produce and 70% TT before shipment . or 100% LC at sight ( irrevocable ).
    Q. How long time you could delivery goods to customer ?
    A : Generally 25 days of working , after we receive your deposits .
    Q:How you can ensure you have deliveried goods to customers ?

    A: We will give you the complete shipping information details for you to confirm.
    Q. How you could supply customers after sales services ?
    A: We will reply you at first time and help you resolve the problems within 24 hours . If it really need us to your local , we will send your professional person to your local to help you resolve problems without any hesitation , supply you all-around after-sales services including machine maintenance and operation and technical training services etc .
